conga-B7E3
COM Express Basic Type 7 Server Class module based on AMD EPYC™ 3000 processor series
- AMD EPYC™ Embedded 3000 Series
- up to 16 Cores, 32MB Cache and 30..100W TDP
- 4x 10 Gigabit Ethernet KR Interface
- Up to 32 PCI Express generation 3 lanes
- Industrial grade variant
- Optional Onboard NVMe SSD up to 1 TB capacity
产品介绍
产品规格
订购资讯
相关配件
资讯下载
产品介绍
产品规格
| Item | Description |
| Formfactor | COM Express Basic |
| CPU |
AMD EPYC™ Embedded 3000 Model 3451 (16 x 2.1 GHz, 32MB L3 cache, 100W)
AMD EPYC™ Embedded 3000 Model 3351 (12 x 1.90 GHz, 32MB L3 cache, 80W)
AMD EPYC™ Embedded 3000 Model 3251 (8 x 2.5 GHz, 16MB L3 cache, 55W)
AMD EPYC™ Embedded 3000 Model 3255 (8 x 2.5 GHz, 16MB L3 cache, 55W)
AMD EPYC™ Embedded 3000 Model 3201 (8 x 1.5 GHz, 16MB L3 cache, 30W)
AMD EPYC™ Embedded 3000 Model 3151 (4 x 2.7 GHz, 16MB L3 cache, 45W)
AMD EPYC™ Embedded 3000 Model 3101 (4 x 2.1 GHz, 8MB L3 cache, 35W)
|
| DRAM | Up to 3 SO-DIMM sockets for DDR4 memory modules up to 32 GByte each (96 GByte total) with 2666 MT/s ECC and non-ECC memory |
| Ethernet |
4x 10GbE with KR interface support
1 x Gigabit Ethernet
|
| I/O Interfaces |
32 x PCI Express GEN 3.0 lanes
4 x USB 3.1 Gen1
4 x USB 2.0
2 x SATA III (6Gb/s)
LPC bus
SPI
2 x UART
SM-Bus
|
| congatec Board Controller | Multi Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Control | Hardware Health Monitoring | POST Code redirection |
| embedded BIOS Features |
OEM Customization
Flash Update
AMI Aptio UEFI
|
| Item | Description |
| Security |
Trusted Platform Module (TPM 2.0) | Secure Root of Trust | Secure Memory Encryption | Secure Encrypted Virtualization
|
| Operating Systems |
Microsoft® Windows 10 Enterprise
Microsoft® Windows Server 2016
RTS Hypervisor
Yocto
Linux
|
| Temperature | Extended Commercial : Operating: 0 to +60°C Storage: -20 to +70°C Industrial: Operating: -40 to +85°C Storage: -40 to +85°C |
| Humidity | Operating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond. |
| Size | 95 x 125 mm (3.74″ x 4.92″) |
订购资讯
| P/N | Product name | Description |
| 048600 | conga-B7E3/3451 | COM Express Type 7 Basic module based on AMD embedded EPYC 3451 16-core processor (dual die) with 2.15GHz up to 3.0 GHz turbo boost, 32MB L3 cache and quad channel DDR4 2666 MT/s memory interface (formerly Snowy Owl). |
| 048602 | conga-B7E3/3351 | COM Express Type 7 Basic module based on AMD embedded EPYC 3351 12-core processor (dual die) with 1.9GHz up to 3.0 GHz turbo boost, 32MB L3 cache and quad channel DDR4 2666 MT/s memory interface (formerly Snowy Owl). |
| 048604 | conga-B7E3/i-3255 | COM Express Type 7 Basic module based on AMD embedded EPYC 3255 8-core processor (single die) with 2.5GHz up to 3.1 GHz turbo boost, 16MB L3 cache and dual channel DDR4 2666 MT/s memory interface (formerly Snowy Owl). |
| 048605 | conga-B7E3/3251 | COM Express Type 7 Basic module based on AMD embedded EPYC 3251 8-core processor (single die) with 2.5GHz up to 3.1 GHz turbo boost, 16MB L3 cache and dual channel DDR4 2666 MT/s memory interface (formerly Snowy Owl). |
| 048606 | conga-B7E3/3201 | COM Express Type 7 Basic module based on AMD embedded EPYC 3201 8-core processor (single die) with 1.5GHz up to 3.1 GHz turbo boost, 16MB L3 cache and dual channel DDR4 2133 MT/s memory interface (formerly Snowy Owl). |
| 048607 | conga-B7E3/3151 | COM Express Type 7 Basic module based on AMD embedded EPYC 3151 4-core processor (single die) with 2.7GHz up to 2.9 GHz turbo boost, 16MB L3 cache and dual channel DDR4 2666 MT/s memory interface (formerly Snowy Owl). |
| 048608 | conga-B7E3/3101 | COM Express Type 7 Basic module based on AMD embedded EPYC 3101 4-core processor (single die) with 2.1GHz up to 2.9 GHz turbo boost, 8MB L3 cache and dual channel DDR4 2666 MT/s memory interface (formerly Snowy Owl). |
相关配件
| P/N | Product name | Description |
| 048652 | conga-B7E3/HSP-HP-B | Standard heat spreader for high performance COM Express Type 7 module conga-B7E3 with integrated heat pipes. All stand-offs are bore hole. Suitable for all single die variants. |
| 048653 | conga-B7E3/HSP-HP-T | Standard heat spreader for high performance COM Express Type 7 module conga-B7E3 with integrated heat pipes. All stand-offs are M2.5 threaded. Suitable for all single die variants. |
| 048656 | conga-B7E3/SP4-HSP-HP-B | Standard heat spreader for high performance COM Express Type 7 module conga-B7E3 with integrated heat pipes. All stand-offs are bore hole. Suitable for all dual die variants. |
| 048657 | conga-B7E3/SP4-HSP-HP-T | Standard heat spreader for high performance COM Express Type 7 module conga-B7E3 with integrated heat pipes. All stand-offs are M2.5 threaded. Suitable for all dual die variants. |
| 048660 | conga-B7E3/HPA | Heat pipe Adapter for conga-B7E3 COM Express Type 7 module. This adapter can be used in combination with standard 8 mm heat pipes to optimize heat distribution. Suitable for all single die variants. |
| 048662 | conga-B7E3/HPA SP4 | Heat pipe Adapter for conga-B7E3 COM Express Type 7 module. This adapter can be used in combination with standard 8 mm heat pipes to optimize heat distribution. Suitable for all dual die variants. |
资讯下载
文件类型
档案名称
更新日期
下载
Datasheet
Data Sheet for conga-B7E3
2024/10/30
Manual
User’s Guide for conga-B7E3
2024/11/11
